Intel Specification |
ATX12V |
|
PFC Type |
Active PFC |
|
ATX Standard |
ATX 3.1 |
|
Dimensions |
160 x 150 x 86 mm |
|
Efficiency |
80Plus Platinum |
|
MTBF |
>120,000 hrs @ 25°C |
|
Protection Features |
OPP/OVP/UVP/SCP/OCP/OTP |
|
Material certification |
ROHS |
|
DC output |
+3.3V +5V +12V -12V +5Vsb |
|
Maximum Load |
25A 25A 100A 0.3A 3A |
|
Combined Load |
130W 130W 1200W 3.6W 15W |
|
Total Output |
1200W |
|
Connection port |
MB 24/20-pin x 1 CPU 4+4-pin x 2 PCI-E 16-pin x 1 (both PSU & component side) PCI-E 6+2-pin x 4 SATA x 6 PERIPHERAL x 3 |
|
Package Contents |
Power Cord x 1 Motherboard Power Cable x 1 (610mm) CPU Cable x 2 (1000mm) PCI-E Gen 5.1 (16-pin-to-16-pin) Cable x 1 (750mm) PCI-E (8-pin-to-6+2pin) Cable x 4 (750mm) SATA 1-to-3 Cable x 2 (400+120+120mm) Peripheral 1-to-3 Cabel x 1 (400+150+150mm) ROG Strix DIY sticker x 1 User Manual x 1 |
|
Weight |
1.84 kg (single PSU) |
|
Cybenetics Noise Level Certification |
TBD |
Nguồn máy tính ASUS ROG STRIX GAMING 1200P (1200W, ATX 3.1, PCIe 5.0, 80 Plus Plantinum, Full Modular, 10 năm bảo hành)
Mô tả ngắn
- Kích thước: 160 x 150 x 86 mm
- Chuẩn nguồn: 80Plus Platinum
- Công suất danh định: 1200W
- Nguồn điện vào: 100-240Vac
- Điện áp đầu ra: +3.3V +5V +12V -12V +5Vsb
8.050.000₫
